Item: PM 01
Fisher & Krecke F 16 S

Year: 2005
Number of colors: 8
Print possibilityes: 8+0
Gearless: Yes
Fast sleeve change: Yes
4 motor per deck CNC position system: Yes
Computer supervision: Yes
Web width (mm): 1220
Print width (mm): 1170
Min print repeat (mm): 320
Max print repeat (mm): 800
Unwinder type: Turret Automatic
Max reel diameter unwinder (mm): 800
Rewinder type: Turret Automatic
Max reel diameter renwinder (mm): 800
Drying: Electric
Videocamera: AVT Jupiter
Web guides: yes in and out BST
Vyscosity control: yes
Washing system: yes automatic
Inking system: closed chamber doctor blades and electric ink pumps
Anilox: 18 ceramic laser engraved sleeves
Print Sleeves: several repeats available
Additional informations: Plate mounter Heaford
UPS unit

F&K 2
F&K 3
F&K 1
